18AWG TSJ UL 83 THERMOPLASTIC INSULATED CABLE, LOW-CURRENT FLEXIBLE CABLE FOR LOW CONSUMPTION APPLIANCES
Conductor:
Class 5, annealed soft fine wires
Insulation:
105°C PVC + Nylon
Jacket:
PVC (BLACK)
Rated Voltage:
600V
Temperature range:
105℃
Standard:
UL62 & UL83
Description
Download


Conductor
Class 5, annealed soft fine wires

Insulation and Sheath
105°C PVC + Nylon & PVC (BLACK)

No. of Conductor
2 cores: black, white
3 cores: black, white, green
4 cores: black, white, red, green

Temperature Rating
105°C
18AWG TSJ UL 83 thermoplastic insulated cable, Low-Current flexible cable for low consumption appliances
18AWG TSJ Cable is a slim, lightweight UL 83 thermoplastic insulated cable engineered exclusively for low-current, light-duty electrical scenarios. As a professional round flexible multiconductor cable, it features ultra-thin, bendable construction for easy wiring in narrow spaces. This cost-effective PVC portable lighting cable is widely utilized for indoor decorative and daily lighting systems. It serves as the perfect flexible cable for low consumption appliances, fully matching the power demand of small daily electronic devices. Meanwhile, it is the ideal wiring solution for TSJ Cable for hotel room lighting and civilian terminal equipment, and commonly made into cable for portable fan power cords for household and office mobile ventilation equipment. With standard 600V rating, stable thermoplastic insulation and long bending life, it is the preferred light-gauge TSJ cord for civilian and commercial light-load wiring projects.

TSJ-N Cable
TSJ-N is typically used inside equipment or in protected environments, primarily for internal wiring in household appliances, wiring within industrial control cabinets and distribution boxes.

Conductors:Class 5, annealed soft fine wires

Rated Voltage Uo/U (Um) : 600V

Insulated & :105°C PVC + Nylon

Jacket: PVC (BLACK)

Standards : UL62 & UL83

Temperature range :105℃
Advantages of TSJ-N Cable
18AWG TSJ-N cable features a unique thermoplastic thermoplastic cable compound structure combining PVC insulationPVC insulation and inner nylon layernylon covering, delivering outstanding tensile strength and exceptional flex life. This lightlight-duty flexible duty flexible cordpower cable is lightweight, compact and highly resistant to moisturemoisture, abrasion resistant flexible cable, abrasion resistant flexible cable and mild oil contamination. It supports repeated bending and moving installation without cracking, ensuring stable electrical performance and longer service life for daily low-powerflexible cable for low consumption appliances wiring applications.

| Core No. x Gauge | Nominal Cross Section Area | Nominal Cover Thickness | Aproximate Total Diameter | Total Weight Approx. | Max. Conductor DC Resistance @ 20 ℃ | ||
| AWG/MCM | mm² | in | mm | in | mm | kg/km | Ω/km |
| 2x18 | 0.82 | 0.030 | 0.762 | 0.231 | 5.859 | 48.45 | 22.40 |
| 3x18 | 0.82 | 0.030 | 0.762 | 0.244 | 6.192 | 58.42 | 22.40 |
| 4x18 | 0.82 | 0.030 | 0.762 | 0.266 | 6.750 | 71.04 | 22.40 |
Certification
This 18AWG TSJ-N cable is manufactured in strict accordance with UL 62 flexible cord cable and UL 83 thermoplastic insulated cable industry standards. All copper conductors comply withASTM B172 copper conductor cable and ASTM B174 copper conductor cable standard specifications. Each batch undergoes rigorous electrical, flame retardant PVC cable and mechanical testing, ensuring full compliance with 600V thermoplastic flexible cable North American flexible cord safety requirements.

Flexibility
Wear Resistance
Oil And Chemical Resistance
UL62 & UL83


APPLICATIONS
Designed specifically for light-load indoor and commercial wiring, 18AWG TSJ multiconductor cable is widely used for low power appliances, office equipment, PVC portable lighting cable, TSJ Cable for hotel room lighting and TSJ Cable for portable fan power cords power connections. It is also ideal for flexible cable for temporary power connections, small fixture wiring and various movable electrical equipment connections.

Portable Power Tools
For power connection of handheld or portable power tools, the cable is flexible and wear-resistant, suitable for frequent movement and repeated bending.

Industrial Sites
Suitable for temporary power connections in factories and construction sites, its oil-resistant and wear-resistant structure can cope with complex operating environments.

Lighting
It is used for powering mobile lighting fixtures and emergency lighting systems, offering good flexibility and convenient wiring and storage.

Protected Outdoor Applications
It can be used for powering outdoor equipment under conditions where there is no direct burial or long-term exposure to sunlight, and has a certain degree of weather resistance and anti-aging ability.
Customer Photos
Exporting to 80+ countries and regions, we bring proven global export experience and trusted wires & cables to customers worldwide.

plant equipment
Our factory is equipped with fully automated processing lines for TSJ flexible cord production. Professional precision testing instruments are used to inspect stranded copper conductors performance, insulation integrity, flexibility and flame retardancy. Standardized production processes ensure stable consistency, high yield rate and large-scale TSJ Cable wholesale supplier capacity for all 18AWG TSJ-N cable orders.






Packaging Information
18AWG TSJ-N Cable are standard packaged in neat coils and sturdy wooden reels for safe long-distance transportation. We support custom color TSJ Cable, personalized packaging, labeling and printing solutions to meet wholesale and OEM requirements.

Coiled

Wooden Reel

Large Wooden Reel
Global Certification
As a professional TSJ Cable manufacturer and exporter, we own more than 50 international certifications including UL, CE, VDE, SAA, TUV and ISO. All American standard TSJ Cable products conform to unified international quality systems, supporting safe sales and project use in global markets.

VDE

UL

SAA

TUV

ISO
What are people saying about us
Global customers highly recognize our TSJ service cord series cables for stable quality, reliable delivery and professional technical support. We maintain long-term cooperative relationships with global buyers with consistent high-quality products and attentive after-sales service.


Luis Fernando Pérez - Venezuela - Office Building Project
The wires are of very good quality. The cables need to pass through long pipes and corners, and the cables are very flexible. We also ordered fire-resistant wires, which have been tested by a testing agency and found to be without problems.


Thomas Baker - USA - Factory construction
GERITEL WIRE's engineering team was very professional. They offered suggestions based on our cable requirements, and we found more suitable cable models. Subsequent operation has been stable without any problems.


Ricardo José Herrera - Dominican - Hotel Project
Due to the tight schedule of the hotel project, we had to adjust the usage quantity several times. GERITEL WIRE supplier was very flexible in terms of delivery and packaging, with fast delivery times. The wire reels were clearly labeled, making on-site counting and distribution very convenient.
frequently asked questions
If you have any questions, you can contact me at any timeDo you have a 24/7 emergency response team to deal with emergencies?
In which regions of the world does your company conduct business?
What after-sales services do you provide?
What is your quality assurance process?
How long is the life of your wires and cables?
Please introduce the founding and development of the company?
What types of wires and cables does your company produce?
Where is your factory?
How long does it take to complete your order?
Do you provide customized wire and cable solutions?
What payment methods are accepted for purchasing wires and cables?
Are your cables certified by industry standards?
